SMB100A/B102 (ROHDE & SCHWARZ)
Генератор РЧ и микроволновых сигналов, 1 канал, 2.2ГГц
The SMB100A/B102 from Rohde & Schwarz is a RF and microwave signal generator with 9KHz to 2.2GHz frequency option. In addition to outstanding spectral purity and high output power, it features easy operation, comprehensive functionality and low cost of ownership. The R&S SMB100A is optimally suited for development, production and service or wherever an analogue RF or microwave signal is required. It can be ideally used for measuring the blocking characteristics. Its low weight and compact design makes it suitable for a wide range of applications including mobile applications. It has a high quality shielding, sensitivity measurements on low-noise satellite receivers can only be made with RF leakage proof signal sources.
- AC input voltage range from 90V to 264V
- Maximum input current is 1.4A (100V) to 0.6A (240V) with 60W
- Output power (PEP) ranging from +18dBm to -120dB
- Standard high power, SMB-B102 includes an electronic step attenuator with step ranges of 5dB
- Setting time of SCPI mode is less than 2.5ms and list mode is less than 1ms
- Remote control via LAN, USB and GPIB including emulation modes for legacy instruments
- All important analogue modulations with AM, FM/?M and pulse modulation supported
- Intuitive user interface with graphical display of signal flow for easy operation
- Temperature range from 0°C to +55°C
- Dimension (W x H x D) is 344mm x 112mm x 368mm and 5.3Kg
Области применения
Тестирование и Измерение
Содержание
SMB100A RF and microwave signal generator, Including power cable, Quick start guide, CD-ROM (with operating and service manual).
Примечания
Для данного продукта доступна услуга калибровки. Возможность выбора услуги стандартной сертификации или международно-признанной аккредитации UKAS. Для получения более подробной информации, посетите нашу страницу калибровки.
Гарантия Производителя:
3 года
Количество Каналов:
1 канал
Линейка Продукции:
-
Модуляция Генератора Сигнала:
AM, FM, PM, ШИМ
Полоса Пропускания:
2.2ГГц
Тип Генератора Сигнала:
Микроволна
Тип Штекера:
-
SVHC (Особо Опасные Вещества):
No SVHC (20-Jun-2016)
RoHS статус:
Да
