R413I21000000M (KEMET)
Конденсатор Безопасности, 10000 пФ, Y2, серия R41, 300 В, PP (Полипропилен)
The R41 Series is constructed of metallized polypropylene film encapsulated with self-extinguishing resin box meeting the requirements of UL 94 V-0. Automotive Grade devices are available (up to 22.5 mm Lead Spacing) and meet the demanding Automotive Electronics Council's AEC-Q200 qualification requirements. For use in electromagnetic interference (EMI) suppression filter in "line-to-ground" and "across-the-line" applications requiring Y2/X1 safety classification. Suitable for use in situations where failure of the capacitor could lead to danger of electric shock. Not for use in "series with mains" type applications.
- Approvals: ENEC, UL, cUL, CQC / Rated voltage: 300 VAC 50/60 Hz
- Class Y2 / X1 (IEC 60384-14)
- Capacitance range: 0.001 - 1 µF / Capacitance tolerance: ±20%, ±10%
- Lead spacing: 10 - 37.5 mm
- Climatic category: 40/110/56, IEC 60068-1 / Operating temperature range of -40?C to +110?C
- Tape and reel in accordance with IEC 60286-2
- RoHS Compliant and lead-free terminations
- 100% screening factory test at 5,000 VDC/2,500 VAC
- Self-healing properties
- Automotive (AEC-Q200) grades available up to 22.5 mm Lead Spacing
Допуск Емкости:
± 20%
Емкость:
10000пФ
Значение dv/dt:
600В/мкс
Класс Подавления Помех:
Y2
Линейка Продукции:
серия R41
Максимальная Рабочая Температура:
110°C
Минимальная Рабочая Температура:
-40°C
Номинальное Напряжение X:
-
Номинальное Напряжение Y:
300В
Стандарты Автомобильной Промышленности:
AEC-Q200
Стиль Выводов Конденсатора:
Радиальные Выводы
Стиль Корпуса Конденсатора:
Радиальная Коробка
Тип Диэлектрика Конденсатора:
PP (Полипропилен)
SVHC (Особо Опасные Вещества):
No SVHC (15-Jan-2018)
RoHS статус:
Да
