C315C101J2G5TA (KEMET)
Многослойный керамический конденсатор, Gold Max, 100 пФ, 200 В, Goldmax, серия 300, ± 5%
KEMET's Goldmax conformally coated radial leaded ceramic capacitors in C0G dielectric feature a 125°C maximum operating temperature. The C0G dielectric is a Class I "stable" material. Components of this classification are temperature compensating and are suited for resonant circuit applications or those where Q and stability of capacitance characteristics are required. C0G exhibits no change in capacitance with respect to time and voltage and boasts a negligible change in capacitance with reference to ambient temperature. Capacitance change is limited to ±30 ppm/°C from -55°C to +125°C. These devices meets the flame test requirements outlined in UL Standard 94V-0.
- Capacitance value ranges from 1pF to 0.47µF
- DC voltage ratings of 25V, 50V, 100V, 200V and 250V
- Available capacitance Tolerances of ±0.1 pF, ±0.25 pF, ±0.5pF, ±1%, ±2%, ±5%, and ±10%
- Extremely low ESR and ESL
- Dimension is 3.81mm x 3.14mm (L x H)
- 2.54mm pitch spacing
- Epoxy encapsulated
- High thermal stability
- High ripple current capability
- No capacitance change with respect to applied rated DC voltage
- No capacitance decay with time
- Non-polar device, minimizing installation concerns
- Capacitance offerings ranging from 1pF up to 0.47µF
- 0.100, 0.200, 0.250 and 0.400" Lead spacing
Области применения
Время и Расчет Времени, Промышленное
Допуск Емкости:
± 5%
Емкость:
100пФ
Линейка Продукции:
Goldmax, серия 300
Максимальная Рабочая Температура:
125°C
Минимальная Рабочая Температура:
-55°C
Номинальное Напряжение:
200В
Стандарты Автомобильной Промышленности:
-
Стиль Выводов Конденсатора:
Радиальные Выводы
Характеристика Диэлектрика:
C0G / NP0
Шаг Выводов:
2.54мм
SVHC (Особо Опасные Вещества):
No SVHC (15-Jan-2018)
RoHS статус:
Y-Ex
