PIC24FJ64GA202-I/SP (MICROCHIP)
Микроконтроллер PIC/DSPIC, AEC-Q100, PIC24 Family PIC24FJ GA Series Microcontrollers, PIC24, 16бит
The PIC24FJ64GA202-I/SP is a 16-bit flash General Purpose Microcontroller with cryptographic engine, ISO 7816 and XLP technology. The PIC24F 16-bit microcontroller featuring integrated Hardware Crypto module and eXtreme low power. This family also includes 64kB flash, 8kB RAM and advanced peripherals. The combination of features makes the part ideally suited for low power embedded security applications.
- Cryptographic engine - Supports ECB, CBC, OFB, CTR and CFB128 modes and programmatically secure
- Extreme low-power - Extreme low-power current consumption for deep sleep
- High-performance CPU - 17-bit x 17-bit single-cycle hardware fractional/integer multiplier
- Analogue - Three on-chip programmable voltage references
- Peripherals - Hardware real-time clock/calendar (RTCC) and three 3-wire/4-wire SPI modules
- 20-year Minimum flash data retention
- Self-programmable under software control
- Programmable reference clock output
- In-Circuit Serial Programming™ (ICSP™) and In-Circuit Emulation (ICE) via 2 pins
- JTAG programming and boundary scan support
- Fail-safe clock monitor (FSCM) operation
- Programmable high/low-voltage detect (HLVD)
- Flexible watchdog timer (WDT) with its own RC oscillator for reliable operation
Области применения
Охрана, Компьютеры и Периферия, Промышленное, Авто
Предупреждения
ESD sensitive device, take proper precaution while handling the device.
Архитектура:
PIC24
Количество I/O:
21I/O
Количество Бит:
16бит
Количество Выводов:
28вывод(-ов)
Линейка Продукции:
PIC24 Family PIC24FJ GA Series Microcontrollers
Максимальное Напряжение Питания:
3.6В
Минимальное Напряжение Питания:
2В
Размер Памяти:
64КБ
Размер Памяти RAM:
8КБ
Семейство Микроконтроллера:
PIC24
Серия Микроконтроллера:
PIC24FJ GA
Скорость ЦПУ:
32МГц
Соответствует Фталатам RoHS:
Да
Стиль Корпуса Микроконтроллера:
SDIP
Тип Встроенного Интерфейса:
I2C, I2S, SPI, UART
SVHC (Особо Опасные Вещества):
No SVHC (27-Jun-2018)
RoHS статус:
Да
