TUSB9261IPVP (TEXAS INSTRUMENTS)
Интерфейсные мосты, USB 3.0 в SATA, 3 В, 3.6 В, HTQFP, 64 вывод(-ов), -40 °C
The TUSB9261IPVP is an ARM® Cortex® M3 Microcontroller based USB 3.0 to serial ATA Bridge provides the necessary hardware and firmware to implement an USB attached SCSI protocol (UASP)-compliant mass storage device suitable for bridging hard disk drives (HDD), solid state disk drives (SSD), optical drives and other compatible SATA 1.5Gbps or SATA 3.0Gbps devices to an USB 3.0 bus. In addition to UASP support, the firmware implements the mass storage class BOT and USB HID interfaces.
- Integrated transceiver supports SS/HS/FS signalling
- Best-in-class adaptive equalizer
- Allows for greater jitter tolerance in the receiver
- USB attached SCSI protocol (UASP)
- USB Mass storage class bulk-only transport (BOT)
- Support for error conditions per the 13 cases
- USB Bootability support
- USB Human interface device (HID)
- Supports firmware update via USB, using a TI provided application
- SATA Interface
- Integrated ARM Cortex M3 core
- Customizable Application Code Loaded from EEPROM by SPI Interface
- Two additional SPI port chip selects for peripheral connection
- Two GPIOs have PWM functionality for LED blink speed control
- Serial communications interface for debug (UART)
- Integrated spread spectrum clock generation
- Green product and no Sb/Br
Области применения
Потребительская Электроника, Переносные Устройства, Аудио, Визуализация, Видео и Зрение
Предупреждения
Device has limited built-in ESD protection. The leads should be shorted together or the device placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.
Количество Выводов:
64вывод(-ов)
Линейка Продукции:
-
Максимальная Рабочая Температура:
85°C
Максимальное Напряжение Питания:
3.6В
Минимальная Рабочая Температура:
-40°C
Минимальное Напряжение Питания:
3В
Соответствует Фталатам RoHS:
Да
Стандарты Автомобильной Промышленности:
-
Стиль Корпуса Интерфейса:
HTQFP
Тип Моста:
USB 3.0 в SATA
SVHC (Особо Опасные Вещества):
No SVHC (27-Jun-2018)
RoHS статус:
Да
