RPS0500DH1R00JB. (VISHAY)
Резистор, винт, 1 Ом, Серия RPS 500, 500 Вт, ± 5%, Винт, 5 кВ
The RPS 500 series Power Resistor for mounting onto a heat-sink. This range has been developed specifically for electrical traction applications and is capable of dissipating 500W at 70°C. The remarkable performance characteristics are evident when used in severe pulse conditions. The copper base allows easy mounting on the heat-sink and provides optimal dissipation conditions. It has cermet resistive element, alumina onto base of nickel coated copper substrate.
- Low thermal radiation of the case
- High overload capability up to 2 times rated power
- Thick film technology
- UL94V-0 Flammability rating
- High Power Resistor
Выводы Резистора:
Винт
Допуск Сопротивления:
± 5%
Класс Мощности:
500Вт
Линейка Продукции:
Серия RPS 500
Номинальное Напряжение:
5кВ
Сопротивление:
1Ом
Температурный Коэффициент:
± 150млн??/°C
Тип Элемента Сопротивления:
Толстая Пленка
SVHC (Особо Опасные Вещества):
To Be Advised
RoHS статус:
Да
