ECF504-12AAS (L-COM)
USB кабель, Гнездо USB Типа A, Штекер USB Типа A, 305 мм, 12 ", USB 2.0, Серый
The ECF504-12AAS is an USB type A Coupler with USB A plug to USB A panel mount receptacle. Another unique panel mount USB option features a bulkhead type A jack to a molded type A plug attached via USB 2.0 compliant cable. This cable can be directly connected to a mating connector inside an enclosure. This assembly is fully shielded and uses L-com's popular ECF504 style housing that can be used with virtually any panel thickness. Twisted pair data lines help reduce crosstalk while 20AWG power conductors enable maximum power transfer from host to peripheral.
- Allows USB cables to be passed through panels or enclosures
- Screw mount for secure installations
- 30µinch Gold plated contacts provide reliable connections with repeated mating cycles
- 20AWG Power leads allow for maximum power transfer
- Connectors are USB A panel mount female to standard USB A male
Области применения
Компьютеры и Периферия, Тестирование и Измерение, Связь и Сеть
Версия USB:
USB 2.0
Длинна Кабеля - Дюймовый:
12"
Длинна Кабеля - Метрическая:
305мм
Линейка Продукции:
-
Разъем A:
Гнездо USB Типа A
Разъем B:
Штекер USB Типа A
Цвет Внешней Изоляции:
Серый
Электронная Маркировка:
-
SVHC (Особо Опасные Вещества):
No SVHC (20-Jun-2016)
RoHS статус:
Да
